1280x1024 300cd/m2 TFT LCD Module 17.0" LM170E03-TLGD 85/85/75/85 (Typ.)(CR≥10

Name: 1280x1024 300cdm2 TFT LCD Module 170quot LM170E03TLGD 85857585 TypCR10
Brand: LG.Philips LCD
Price: 1 USD

China 1280x1024 300cd/m2 TFT LCD Module 17.0" LM170E03-TLGD 85/85/75/85 (Typ.)(CR≥10 factory

Brand Name : LG.Philips LCD

Model Number : LM170E03-TLGD

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 120PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LM170E03-TLGD

BRAND : LG.Philips LCD

SIZE : 17.0INCH

BRIGHTNESS : 300CD/M2

Lamp Type : WLED

RESOLUTION : 1280(RGB)×1024 (SXGA) 96PPI

VIEWING ANGLEG : 85/85/75/85 (Typ.)(CR≥10

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG Display LM170E03-TLGD Application Details

Basic Information :	Brand LM170E03-TLGD 3 CompatibleModel Type a-Si TFT-LCD , LCM Used For 17.0 inchScreen Size Alias LM170E03 (TL)(GD)
Environment :	Storage Temp. -20 ~ 60 °C Operating Temp. 0 ~ 50 °C

LG Display LM170E03-TLGD Mechanical Details

Pixel Features :	Resolution 1280(RGB)×1024, SXGA Dot Pitch(mm) 0.088×0.264 (H×V) Pixel Format RGB Vertical Stripe Pixel Pitch(mm) 0.264×0.264 (H×V) [96PPI]
Mechanical Size :	Active Area(mm) 337.92(H) × 270.336(V) Bezel Area(mm) 341.6(H) × 274.0(V) Outline Dim.(mm) 358.5(H) × 296.5(V) Depth(mm) 16.0±0.5
Outline Features :	Form Style Flat Rectangle Shape Style Normal bezel Aspect Ratio 5:4 (H:V) Orientation Landscape type
Mounting :	Side mounting holes (4-M3) on left, right bezel
Other Spec :	Weight 1.60/1.68Kgs (Typ./Max.) Treatment Antiglare, Hard coating (3H)

LG Display LM170E03-TLGD Optical Details

Basic Information :	Luminance(cd/m²) 300 (Typ.) Contrast Ratio 1000:1 (Typ.) (Transmissive) Viewing Angle 85/85/75/85 (Typ.)(CR≥10) Display Mode TN, Normally White, Transmissive Best View on 6 o'clock Response(ms) 1.2/3.8 (Typ.)(Tr/Td)
Color Performance :	White Coordinate Wx:0.313; Wy:0.329 Display Colors 16.7M (6-bit + Hi-FRC) Color Temperature 6485K White Uniformity 1.33 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio 71% sRGB 96% coverage Adobe RGB 74% coverage DCI-P3 74% coverage Rec.2020 53% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LM170E03-TLGD Interface Detail

Signal Electrical :	Voltage Supply 5.0V (Typ.) Current Supply 950/1090mA (Typ./Max.)
Signal Type :	LVDS (2 ch, 8-bit) Logic Voltage -
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Quantity Pin Configuration UJU IS100-L30B-C23 1.0 mm 30 pins 1 pcs LVDS-30P2C8B-160C

LG Display LM170E03-TLGD Backlight Details

Backlight Features :	Type CCFL Quantity 4 pcs Position Edge light type (Top and Bottom) Replacement - Shape Straight Life Time 50K(Min.) (Hours)
Lamp Electrical :	Voltage Supply 628/640/745V (Min./Typ./Max.) Current Supply 2.5/7.0/7.5mA (Min./Typ./Max.) Frequency 40/60/70KHz (Min./Typ./Max.) Startup Voltage 1000/1250V (Max.)(Ta=+25/0℃) Consumption 17.9/19.7W (Typ./Max.)
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Quantity Pin Configuration YEONHO 35001HS-02LD 3.5 mm 2 pins 4 pcs BLL-2PINS-HL
Backlight Driver :	No

LG Display LM170E03-TLGD Packing Details

Package Box :	Quantity	Weight	Box Size
Package Box :	10 pcs / box	-	420×333×431 mm (L×W×H)

Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
